Surface grinding

The steel needle whose angle on the elastic card clothes changes are processed by surface grinding technology to make the whole card cloth flat and the blade angle of the steel needle are consistent.

The actual operation as shown in the figure:The grinding head conducts transverse reciprocating motion. A flat grinding wheel is installed on the grinding head. The grinding wheel is rotated at high speed and the steel needle on the elastic card cloth are grinded so as to realize the technological requirements of the overall grinding of the steel needle.

The product structure is mainly composed of four parts: (1) Grinding head assembly, (2) Guide rail assembly, (3) Bracket assembly, (4) Electrical control box.

1. The grinding precision of the product is within 0.03mm, comparable to imported products.

2. The electronic control and mechanical parts of the product are integrated, with high integrity and easy to

install.

3. The product is light and use a lot of aluminum material, running light.

4.  Low maintenance cost without refueling when the product is running.

5. The grinding precision and linear speed of the product are controlled by button, and the operation is

simple.

6. The track is made of high quality alloy steel, which is not easy to deform after quenching。

7. The product quality is stable, and the after-sales service is perfect, so that customers have no worries.

8.  Wide range of products can meet the needs of most customers.

It is suitable for all kinds of carding machines.
